TUBULAR

Extractor en Linea TD QB HF-100 198 m3h. 15.6 mmcda. 220 volt. 26 W. 31 dBA. Ducto 100 mm Ø o 4

Extractor en Linea TD QB HF-125 284 m3h.15.9 mmcda. 220 volt. 33 W. 31 dBA. Ducto 120 mm Ø o 5

Extractor en Linea TD QB HF-150 530 m3h. 30 mmcda. 220 volt. 54 W. 33 dBA. Ducto 150 mm Ø o 6

Extractor en Linea TD QB HF-200 840 m3h. 35.2 mmcda. 220 volt. 128 W. 39 dBA. Ducto 200 mm Ø o 8

Extractor en Linea TD QB HF-250. 1400 m3h. 48.8 mmcda. 220 volt. 225 W. 66 dBA. Ducto 250 mm Ø o 10

Extractor en Linea TD QB HF-315. 2.206 m3h. 69.3 mmcda. 220 volt. 390 W. 60 dBA. Ducto 315 mm Ø o 12

Extractor Ultra silent HDD 125 Mix Vent Silent 220 v. 33watts. 2250rpm. 284 m3h. Ducto 120 mm Ø o 5

Extractor Ultra silent HDD 150 Mix Vent Silent 220 v. 50 watts. 2250rpm. 530 m3h. Ducto 150 mm Ø o 6

Extractor Ultra silent HDD 200 Mix Vent Silent 220 v. 128 watts. 2250rpm. 840 m3h. Ducto 200 mm Ø o 8

Extractor tubular KT-40-5 8.050 m3h 380 volt 750W 15 mmda

Extractor tubular KT-40-6 13.900 m3h. 380 volt. 1.5 kw. 1450 rpm. 21 mmcda

Extractor tubular KT-40-7 22.100 m3h. 380 volt 3.0 kw 1450 rpm 30 mmcda

Extractor tubular KT-40-8 33.000 m3h 380 volt 5.5 kw 1450 rpm 39 mmcda

Extractor tubular axial BTFM-400 6 230V 370W 4.000 m3h 40 cm Ø 20 kg

Extractor tubular axial BTFM-500 6P 230V 550W 8.000 m3h 50 cm Ø 30 kg

Extractor tubular axial BTFM-560 6P 380V 750W 11.000 m3h 56 cm Ø 36 kg

Extractor tubular axial BTFM-630 6P 380V 1100W 15.000 m3h 63 cm Ø 40 kg

Extractor de tunel PYHL 5A 15 Kw 18.000 m3h 160 mmcda 2900 rpm 190 kg

Extractor de tunel PYHL15 7.5A Kw 30.411 m3h 124 mmcda 1450 rpm 308 kg
